Rated input DC power 1 450 W 600 W
Absolute max. input voltage 80 V
MPPT operating voltage range 10–80 V
Max. short-circuit current (Isc) 14.5 A
Max. efficiency 99.5%
Weighted efficiency 99.0%
Overvoltage category II
Output
Max. output voltage 80 V
Max. output current 15 A
Output bypass 2 Yes
Output voltage during standby 3 0 V
Output impedanceduring standby 1 kΩ ± 10%

Communication protocol MBUS
Standards Compliance
Safety IEC62109-1 (class II safety)
RoHS Yes
Fire Safety VDE-AR-E 2100-712:2018-12
General Specifications
Dimensions (W x H x D) 75 mm x 140 mm x 28 mm (3.0 in. x 5.5 in. x 1.1 in.)
Weight (including cables) 0.6 kg (1.3 lb.)
Installation part (optional) Frame mounting bracket/T-shaped bolt 4
Input connector Staubli MC4
Input wire length 0.15 m (0.49 ft.)
Output connector Staubli MC4
Output wire length 1.3 m (4.3 ft.)
Operating temperature/humidity range –40°C to +85°C 5
/0%-100%
IP rating IP68
