7DH5A007EA 4124P 4C/3.8G/65W 1x 16GB IOB SATA / AHC 2x3.5" bay; 2x 960GB SATA HDD Opt Opt 500W Yes Yes

Machine type 7DH4 - 1 year warranty
7DH5 - 3 year warranty
Form factor Tower, Processor  ,One AMD processor. Choose from:

AMD EPYC 4004 CPU Support up to 65W with 12 cores, with core speeds up to 3.8 GHz
Chipset AMD PROM21 Chipset: PRO-665
Memory Two DIMM sockets supporting Lenovo TruDDR5 DIMMs at 5600 MHz. Support ECC UDIMMs.
Memory maximums Up to 64 GB using 2x 32 GB UDIMMs.
Memory protection Error-correcting code (ECC)
Disk drive bays
Up to 4x non-hot swap (NHS) drive bays:

3x 3.5-inch NHS drive bays supporting HDDs or SSDs
1x 2.5-inch NHS drive bay supporting an SSD
The server can be configured with HDDs or SSDs. The server also supports 2x NVMe M.2 drive installed in a socket on the system board as a boot drive.

Maximum internal storage
3.5-inch drives:
24TB using 3x 8TB 3.5-inch HDDs
2.5-inch drives:
960GB using 1x 960GB 2.5-inch SATA SSDs
HDDs and SSDs can be installed in the same server but are not supported in the same RAID volume

Storage controller
Onboard 6 Gb SATA controller, supporting AHCI mode (non-RAID)
RAID 5350-8i adapter (for 3x 3.5" HDD)
4350-8i SAS/SATA 12Gb HBA
AMD software RAID (Planned for 1Q/2025)
Optical drive Optional slim DVD-RW drive in dedicated bay.
Network interfaces One integrated Gigabit Ethernet 1000BASE-T port (RJ-45), Realtek RTL8111FP.
PCI Expansion slots Two PCIe slots as follows:
Slot 1: PCIe 3.0 x16 full-height half-length (FHHL) (75W)
Slot 3: PCIe 3.0 x1 full-height half-length (FHHL) (25W)
Ports
Front ports:

Five USB ports
1x USB 3 (5 Gb/s) with USB-C connector
4x USB 3 (5 Gb/s) with USB-A connector
Microphone port*
Headset port*
Rear ports:

Four USB 2.0 ports
Two DisplayPort 1.4 video ports
One HDMI 2.1
One RJ-45 Gigabit Ethernet port
One audio line-out port*
* Windows 11 only; some line noise is possible

Audio Mono amplifier (speaker) mounted on the inside of the front bezel; Audio line-out port at the rear of the server; microphone and headset ports at the front of the server
Cooling Two fixed system fans. One CPU heat sink fan. Supports ASHRAE A2 environments.
Power supply
Model dependent choices

One fixed 300W Gold power supply
One fixed 500W Platinum power supply: Energy Star and ErP Lot 9 compliant.
Hot-swap parts None
Systems management
Power and drive activity LEDs. Supports Lenovo XClarity Provisioning Manager Lite (USB memory key-based) for system setup and firmware upgrades. No support for XClarity Controller (XCC).

Security features Power-on password, administrator's password, Trusted Platform Module (TPM), supporting TPM 2.0. Optional Chassis intrusion switch. Padlock loop and Kensington cable slot for physical security.
Video Two DisplayPort ports and native HDMI support resolution (4K) at a refresh rate of 60Hz.
Operating systems supported Microsoft Windows Server, Red Hat Enterprise Linux, SUSE, Ubuntu, Windows 11 tested. See the Operating system support section for specifics.
Limited warranty Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD).
Service and support Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time, 6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and some third-party applications.
Dimensions Width: 170 mm (6.7 in.), height: 376 mm (14.8 in.), depth: 316 mm (12.4 in.). See Physical and electrical specifications for details.
Weight Maximum: 8.56 kg (18.90 lb)
